DH99-IIDE
Ultrasonic Tissue Homogenizer
Power 1800W, crushing capacity 0.5-2000ml

Ultrasonic tissue homogenizer, DH99-IIDE, is a multifunctional and versatile instrument that uses strong ultrasound to produce cavitation effects in liquids for ultrasonic processing of substances. It can be used for the disruption of various animal and plant cells, virus cells, as well as for emulsification, separation, homogenization, extraction, defoaming, cleaning, and acceleration of chemical reactions, and more.

Product Introduction
Ultrasonic tissue homogenizer, DH99-IIDE, is a multifunctional and versatile instrument that uses strong ultrasound to produce cavitation effects in liquids for ultrasonic treatment of materials. It can be used for the homogenization of various animal and plant cells, virus cells, as well as for emulsification, separation, homogenization, extraction, defoaming, cleaning, and acceleration of chemical reactions, among other applications.

Product Introduction

Ultrasonic tissue homogenizer, DH99-IIDE, is a multifunctional and versatile instrument that uses strong ultrasound to produce cavitation effects in liquids for ultrasonic treatment of materials. It can be used for the homogenization of various animal and plant cells, virus cells, as well as for emulsification, separation, homogenization, extraction, defoaming, cleaning, and acceleration of chemical reactions, among other applications.

Product Features
◆7-inch large screen display, more intuitive parameters and more convenient touch operation
◆Simultaneous display of ultrasonic power simulation waveform and ultrasonic time pulse width waveform
◆Rich functions: cell disruption, homogenization, separation, extraction, defoaming, cleaning and accelerating chemical reactions
◆Alarm function: time, overload, no-load, and over-temperature
◆Customizable settings for ultrasonic time, interval time, total time, and power ratio
◆Convenient operation: centrally controlled by a microcomputer for optimized interaction experience
◆Low noise: equipped with a soundproof box to stay away from noise annoyance
◆Long-term operation: supports continuous operation for more than 1 hour

Experiment Objectives
1. Understand the basic principles of ultrasonic cell disruption
2. Master the basic techniques of ultrasonic cell disruption

Principle of the Experiment
When intense sound waves act on a solution, the phenomenon of cavitation, in which bubbles are produced, enlarged, and broken, is induced. The shock waves and shear forces caused by cavitation lead to cell lysis.

Materials and reagents
10 ml bacteria, beaker, ice shaver, 75% alcohol cotton ball.

Technical Parameters
Model:	DH99-IIDE
Frequency:	20-25KHz (auto tracking)
Power:	1800W
Random Amplitude Rod:	Φ20
Optional Amplitude Rod:	Φ2, 3, 10, 15, 25
Crushing Capacity:	0.5-2000ml
Duty Ratio:	1-99%
Screen Size:	7 inches
Screen Material:	High-definition TFT touch screen
Single Ultrasonic Time:	0.1-99.9s
Single Gap Time:	0.1-99.9s
Total Time:	1-99H59M59S
Temperature Control Function*:	Yes (auto pause ultrasonic when reaching preset temperature)
Optional Functions:	PC communication + remote control + user password protection + data printing + automatic lifting sound insulation box + lighting or sterilization
Data Storage:	20 groups
Power Supply:	220/110V 50Hz/60Hz
Power Supply Box Size:	410225290mm
Sound Insulation Box Size:	470305430mm
Net Weight:	16.6kg
Main unit + transducer weight:	20.0kg
Package size:	534×295×435mm

Probe Model Selection
Model	Cell Disruption Capacity
Φ2mm	150ul－5ml
Φ3mm	200ul－10ml
Φ6mm	10ml－200ml
Φ10mm	50ml－500ml
Φ12mm	50ml－700ml
Φ15mm	50ml－1000ml
Φ20mm	100ml－1500ml
Φ25mm	100ml－2000ml

Single Page - Color Page
Name:	Author:	Action:
Ultrasonic Tissue Homogenizer DH99-IIDE	ultrasonic	Download

Product List

DH99-IIDE	Unit
Host Machine	Unit
Vibration System (Transducer Assembly)	Set
Soundproof box	set
Cross clamp (inside the soundproof box)	piece
Test tube clamp (inside the soundproof box)	piece
Special Wrench (used for disassembling the amplitu	Set
Fuses	piece
Power cord	piece
User manual	copy
Warranty card	copy
Certificate of qualification	copy

Description: 1; 1; 1; 1; 1; 1; 8A, 5A each 2; 1; 1; 1; 1
