• Handheld Ultrasonic Homogenizer
  • DH-400
  • Power 400W, crushing capacity 0.5-300ml.
  • DH-400
  • Handheld Ultrasonic Homogenizer
  • Power 400W, crushing capacity 0.5-300ml.
Handheld ultrasonic homogenizer is a new product with full functions and reliable performance. The instrument adopts LED display and has two working modes: automatic and manual (foot switch). The ultrasonic time and power can be arbitrarily set, and the sample temperature can be detected and displayed. The frequency can automatically track.
Product Introduction
DH-400 handheld ultrasonic cell crusher is a multifunctional and versatile instrument that uses the cavitation effect of ultrasound in liquid. It can be used for the crushing of various animals, plants, viruses, cells, and bacteria. It can also be used for emulsification, dispersion, homogenization, extraction, defoaming, cleaning, preparation of nanomaterials, dispersion, and acceleration of chemical reactions, among other applications.
Handheld ultrasonic cell crusher is a new product with full functionality and reliable performance. The instrument adopts LED display and has two working modes: automatic and manual (foot pedal). The ultrasonic time and power can be arbitrarily set, the sample temperature can be detected and displayed, and the frequency can be automatically tracked.


Product Features
It can be used for 96-well ELISA and numerous small test tubes arranged in a handheld ultrasonic transducer. By controlling the ultrasonic waves in a pulse mode, multiple samples can complete ultrasonic processing in a short period of time.
◆ Used for the crushing of animal and plant cells, bacteria, spores or tissues, extraction of proteins from cells, and scientific cultivation experiments of viruses and vaccines.
◆ Accelerate the reaction rate of chemistry, physics, and other fields, as well as accelerate liquid degassing.
◆ Research analysis of crude oil dilution, oil-water emulsification, accelerating crystal removal, and glass pulp homogenization, etc.
◆ Dispersion of rare earth, various inorganic minerals, and preparation of near-nanometer latex homogeneous mixture.
◆ Quick and powerful high-precision cleaning liquid for mold micropores and blind holes.


Technical Parameters
Model: DH-400
Frequency: 19.5-20.5KHz
Power: 400W
Random Amplitude Bar: Φ6
Optional Amplitude Bars: Φ2 / Φ3
Crushing Capacity: 0.5-300ml
Temperature Control: Ultrasonic protection with alarm function
Control Mode: Automatic, manual switchable (optional foot switch)
Pulser: Closed loop 0.1-99s adjustable, open loop 0.1-99s adjustable
Duty Ratio: 1-99%
Power Supply: 220/110V 50Hz/60Hz
Power Supply Case Size: 270*200*140mm
Net Weight: 9.1kg
Main Unit + Transducer Weight: 10.8kg
Package Size: 510×275×390mm


Probe Model Selection
Model Cell Disruption Capacity
Φ2mm 150ul-5ml
Φ3mm 200ul-10ml
Φ6mm 10ml-300ml
Product List
DH-400 Unit
Host Machine Unit
Transducer independent support pair
Soundproof box set
Special Wrench (used for disassembling the amplitu Set
Power cord piece
User manual copy
Warranty card copy
Certificate of qualification copy
Description
1
1
Optional
1
1
1
1
1
