Technical Parameters |
|
|
Model: |
VCX 130 |
|
Frequency: |
20KHz |
|
Power: |
130W |
|
Timing device: |
1s-10hr |
|
Pulse excitation device: |
Off: Manual On: 1-59 seconds adjustable |
|
Inverter model: |
CV18 |
|
Standard amplitude bar: |
Φ6mm |
|
Standard amplitude bar length: |
113mm |
|
Overall size of amplitude bar: |
115 x 250 x 320 mm |
|
Amplitude bar material: |
Titanium alloy Ti-6Al-4V |
| Standard amplitude bar processing capacity: |
10ml to 50ml |
| Optional amplitude bar: |
Φ2mm, Φ6mm, Φ13mm |
| Amplitude bar weight: |
340g |
| Amplitude bar cable length: |
1.5m |
| Duty cycle: |
1-99% |
| Power adjustment range: |
Continuously adjustable (20-130w) |
| Temperature protection setting: |
/ |
| Power amplitude display: |
Yes |
| Working frequency range: |
Energy monitor digital wattmeter automatic tuning and automatic amplitude compensation |
| Working mode: |
Pulse/continuous |
| Power supply: |
220/110V 50Hz/60Hz or unless otherwise specified, the power requirement is sent at 117V, 50/60Hz |
| Net weight: |
3.2kg |
| Main unit + transducer weight: |
3340g |
