Technical Parameters |
|
|
Model: |
VC 505 |
|
Frequency: |
20KHz |
|
Power: |
500W |
|
Sealed frequency converter model: |
CV334 (PZT piezoelectric frequency converter made of lead zirconate titanate) |
|
Standard amplitude bar: |
Φ13mm |
|
Standard amplitude bar length: |
113mm |
|
Overall size of amplitude bar: |
235 x 190 x 340 mm |
|
Amplitude bar material: |
Titanium alloy Ti-6Al-4V |
|
Standard amplitude bar processing capacity: |
50ml to 250ml |
|
Optional amplitude bar: |
Φ6mm, Φ10mm |
|
Amplitude bar weight: |
900g |
|
Amplitude bar cable length: |
1.8m |
|
Crushing capacity: |
50ml to 250ml |
|
Duty cycle: |
1-99% |
|
Power regulation range: |
Continuously adjustable (20-500w) |
|
Gap time: |
0.1-99.9s |
|
Temperature protection setting: |
None |
|
Power amplitude display: |
Yes |
|
Operating frequency range: |
Energy monitor digital wattmeter, automatic tuning, automatic amplitude compensation |
|
Operating time: |
Microprocessor-based programmable 10-hour timer, 1-59 seconds independent/pulse-off |
|
Ultrasonic time: |
From 1 second to 10 hours |
|
Operating mode: |
Gap/Continuous |
|
Power supply: |
220/110V 50Hz/60Hz or 117V, 50/60Hz unless otherwise specified |
|
Net weight: |
6.8kg |
|
Weight of host + transducer: |
9.6g |
